2013 PRIVILEGE 45 - New Boat Library
Length
44' 2" - 13.45m
Model Year
2013
Hull Material
Composite
Description: Privilege 45
Privilege 445 Sailing Catamaran
The choice of many cruising couples around the world, this is the smallest Catamaran in the range but is large in volume and fleet of foot.
The GALLEY UP LAYOUT has proved to be very popular with long distance sailing couples.
The high volume hulls make for excellent load carrying and spacious owners accommodation.
The fabulous protected cockpit and elevated steering station are praised by everyone who steps aboard.
Perfectly suited for Australian & Pacific cruising
The choice of many cruising couples around the world, this is the smallest Catamaran in the range but is large in volume and fleet of foot.
The GALLEY UP LAYOUT has proved to be very popular with long distance sailing couples.
The high volume hulls make for excellent load carrying and spacious owners accommodation.
The fabulous protected cockpit and elevated steering station are praised by everyone who steps aboard.
Perfectly suited for Australian & Pacific cruising
Model Year
2013
Designer
Marc Lombard
Builder
Privilege Marine
Length
44' 2" - 13.45m
Beam
23'
Draft
4'
Displacement
Light 19620lbs
Keel / Ballast
Fixed Keels
Hull Material
Composite
Deck Material
Composite
Engine
Twin Volvo 40hp Sail Drive Diesels with Fixed 3 Blade Propellers. Engine room: 2x Sound Proof Engine Compartments, access via Aft Cabins or Engine Hatch Aft of Cockpit, 1x Water Pump Unit with Expansion Vessel
Fuel
2x Aluminium Fuel Tanks (Total 110 Gal) with Gauge
Water
158 Gal Stainless Steel Fresh Water Tank with Gauge
Accommodation
4x Double Cabins located Fore & Aft in each Hull with Slatted Base and Bultex Type Foam Mattress, Hanging Locker, Stowage, Cubby Holes, Book Shelves, 2x Deck Hatches and One Opening Port in each Cabin, 1x 220vlt Socket, Saloon with Dining Area, Galley and Navigation Area, Light Maple Gloss Varnished Wooden Interior, Laminated Wenge Marine Ply Floors, Curtains Throughout, Banquette Seating covered in either Polyester Microfibre or "Puma" type covering, Headroom in Saloon 1.95mts, 1x C-Shaped Banquette with One Director's Chair, 1x Table with Seating for 8, Stowage in Banquette, 1x Navigational Position fitted with Chart Table, Electrical Distribution Panel & Instrument Panel, 1x Hinged Chart Table Light, 1x Pouffe, 1x Fitted Gangway in Port Hull with 1x Hanging Locket, Ample Stowage, 1x Fitted Gangway in Starboard Hull with 1x Oilskin Locker, 1x Technical Storage Unit, Ample Stowage
Galley
1x Fitted Galley Fully Equipped with 1x Twin Stainless Steel Sink, 1x 3 Ring Hob with Pan Holder + Oven, 1x Waste Bin with Access Hole in Worktop, 1x 40lt Hot Water Tank (220vlt + Engine Heat Exchanger), Ceramic Single Lever Mixer Taps
Refrigeration
1x 160lt 12vlt Refrigerator, 1x 110lt 12vlt Freezer in Port Hull
Shower
4 Showers
Toilet
4 Heads
Covers
1x Stainless Steel Fixed Bimini with Front Window & Light
Ground Tackle
1x Electric Windlass in Chain Locker, 1x Stainless Steel Plate Anchor Chain Protection, Anchor Locker, 8x Fenders, 4x Mooring Lines, 1x Main Mooring with 20kg Delta Anchor + 50mt of Chain, 1x Secondary Mooring with 20kg Brittany Anchor + 25mts of Chain & 50mts of Grapnel Line, 1x Mooring Bridle, 1x Emergency Tiller, 1x Antifouling, 1x Launch, Masting and Sea Trials
Safety Gear
2x Life Lines, 2x Escape Hatches, 2x Hand Operated Bilge Pumps, 4x Electric Bilge Pumps
Electrics
1x Courtesy Lights (2 per Companionway), 2x 220vlt Power Sockets, 1x Transom Lighting (2x Lights per Transom), 1x Charger/Inverter 100A/2000watts/12vlts, 2x 100A Engine Batteries, 5x 100A Auxilliary Batteries, Spots & Fluorescent Lights throughout the Boat, 220 Vac 50 Hz Shore Supply Inlet, 12vlt DC Voltmeter with Low Voltage Warning, DC Ammeter, AC Ammeter, 220vlt V Voltmeter, Cigarette Lighter Socket, Master Electrical Distribution Panel
Electronics
1x Mechanical Wind Vane, Compass, 1x Electronic Navigation Console (Log/Speedo/Wind Direction/Anemometer/Echo Sounder), 1x VHF Transceiver, 1x AM/FM Radio Receiver/CD MP3 Player with 2 Speakers in Saloon + 2x External Speakers, 1x Auto Pilot, 1x Navigation Unit Repeater by Chart Table
Sail Inventory
1x Set of Sails comprising 1x 721sq ft Fully Battened 3 Reef Mainsail, 1x 506 sq ft Genoa on Furler with Anti-UV Strip
Mast / Rigging
61' White Lacquered Light Alloy Mast with 8/9 Rigging fitted with Ball Bearing Mounted Mainsail Luff Slides, 1x Pair of Spreaders with Leather Protection, 3 Steps on Mast, 1x 20' White Laquered Aluminium Boom fitted with 1x Lazy Jack with Fittings, Blocks with Jam Cleats for Reef Lines, 1x Lazy Bag, 1 Set of Standing Rigging (Sleeved, except for Forestay & Diamonds) with 1x Inner Stay, 1x Forestay, 2x Lower Shrouds, 2x Shrouds, 2x Diamond Interiors and Exteriors, 1 Set of Running Rigging with 1x Topping Lift, 1x Genoa Halyard, 1x Mainsail Halyard, 1x Staysail/Storm Jib Halyard, 1x Mainsheet, 2x Genoa Sheets, 1x Mainsail Outhaul, 1x Genoa Furler Line, 3x Reef Lines, 2x Mainsail Car Lines
Deck Gear
2x Aft Transoms, Set of Navigation Lights, Anchor Light and Deck Spot, 1x ST Winch for Mainsail, Halyards and Foot, 1x Cleat for Halyards and Topping Lift, 5x Jam Cleats, 1x Deck Shower on One Transom, 1x Swim Ladder in One Transom Locker & 2x Swim Ladder Handles, 1x Bow Fitting with Double Fairlead, 1x Mast Foot Block for Mainsail Halyard returned to Windlass, 1x Mainsheet Track with 2 Stops, Car and Blocks, 1x ST Winch for Mainsail Car Lines, 2x Mainsail Car Jammers, 1x Mainsheet Tackle Jammer, 2x White Plastic Sleeved Stainless Steel Guardrails all around, 2x Genoa Tracks with Genoa Cars, Blocks, End Stops and Jammers on Coachroof, 2x ST Genoa, Gennaker Sheet Winches on Coachroof, and Port Side Mainsail Sheet, 1x ST Winch for Genoa Furler Lines, 3x Winch Handles and Handle Boxes, 3x Bags for Sheets, 1x Genoa Furler, 7x Stainless Steel Mooring Cleats + 2 Extra on Transom, 2x Stainless Steel Bow Pulpits with Teak Seat and Navigation Lights, 1x Helm Console with 2 Seat Banquette, Engine Controls, Instrument Panel & Compass, 1x Table with Banquette Seat, 1x Leather Covered Aluminium Steering Wheel, 1x Rubber Protection on Transom Skirts, 2x Hand Rails on Coachroof, 2x Stainless Steel Reinforced Davits with Jam Cleats, Stainless Steel Anti Chafing Plates for Mooring Lines, 3x Hatchs Way + 2x Portholes in Side Windows, 1x Self Draining Cockpit with Life Raft Locker, Locker for Rope, Emergency Anchor, and Misc Equipment, Batyline Sunbeds, 1x Set of Batyline Cockpit Cushions, Stainless Steel Backs with Cushions for Cockpit Seats, 1x Large Sail Locker in Pod (Rostrum) with Deck Hatch, 2x Forepeak Lockers with Deck Hatches
Remarks
The choice of many cruising couples around the world, this is the smallest Catamaran in the range but is large in volume and fleet of foot.
The GALLEY UP LAYOUT has proved to be very popular with long distance sailing couples.
The high volume hulls make for excellent load carrying and spacious owners accommodation.
The fabulous protected cockpit and elevated steering station are praised by everyone who steps aboard.
The GALLEY UP LAYOUT has proved to be very popular with long distance sailing couples.
The high volume hulls make for excellent load carrying and spacious owners accommodation.
The fabulous protected cockpit and elevated steering station are praised by everyone who steps aboard.
